Ralston

Ralston Dual Pressure Field Gauge LC20

Model LC20-DS

Ralston LC20 dual-sensor field gauge: two pressure sensors in one gauge, ±0.1% FS accuracy on each (ASME B40.100 Grade 4A), 15 engineering units, IP67, ISO 17025 accredited calibration certificate.

From $1,018.40list price

Pick your exact configuration in the ordering table below to add it to your cart.

Same-day response on quotes. ISO/IEC 17025 accredited calibration available.

Overview

The Ralston LC20 dual-sensor field gauge puts two pressure sensors in one LC20 housing. For example, LC20-GP2M-GB2M-00 has a 1,000 psi bottom sensor and a 5 psi top sensor, both on 1/4" male NPT. Per Ralston, the LC20 shows high and low values on-screen, switches between 15 engineering units or custom units, and includes FieldLab Desktop PC software for calibration, testing and live viewing. Sensor ranges vary by model.

Related

Single-sensor version: Ralston LC20 field gauge. Panel-mount dual-sensor version: Ralston LC30 dual-sensor gauge.

Specifications

Key specifications (Ralston datasheet)
Accuracy (each sensor)±0.1% of full scale (ASME B40.100 Grade 4A / ISO class 0.1)
Example modelLC20-GP2M-GB2M-00: 1,000 psi bottom sensor (burst 4,000 psi) + 5 psi top sensor (burst 20 psi)
Process connections (example model)1/4" male NPT (ASME B1.20.1), bottom and top
Engineering units15, including psi, bar, kPa, MPa, inHg, mmHg, Torr, kgf/cm²
Display2.4 in (61 mm) backlit segmented LCD
Power2 × AA alkaline, about 1,000 hours
Data loggingPC based via USB (Micro B)
Ingress protectionIP67 (1 m submersion for 30 minutes)
Wetted materials316 stainless steel
Operating temperature−4 to 120 °F (−20 to 50 °C)
Calibration certificateISO 17025:2017 accredited

Documents

Build your part number

Configure your LC20

Pick your options and we'll build the exact part number with a list-price estimate.

Select a range to build your part number.

Ordering information

69 ordering models available.

ModelDescriptionList Price
LC20-GP2M-GB2M-00LC20 pressure gauge, 1000 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GP2M-GB2M-B1LC20 pressure gauge, 1000 psi bottom, 5 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.40
LC20-GP2M-GC2M-00LC20 pressure gauge, 1000 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GP2M-GC2M-B1LC20 pressure gauge, 1000 psi bottom, +/-15 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GP2M-VF2M-00LC20 pressure gauge, 1000 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GP2M-VF2M-B1LC20 pressure gauge, 1000 psi bottom, -15 to 30 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GP2M-VJ2M-00LC20 pressure gauge, 1000 psi bottom, -15 to 100 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GP2M-VJ2M-B1LC20 pressure gauge, 1000 psi bottom, -15 to 100 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GR2M-GB2M-00LC20 pressure gauge, 3000 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GR2M-GB2M-B1LC20 pressure gauge, 3000 psi bottom, 5 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GR2M-GC2M-00LC20 pressure gauge, 3000 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GR2M-GC2M-B1LC20 pressure gauge, 3000 psi bottom, +/-15 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GR2M-VF2M-00LC20 pressure gauge, 3000 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GR2M-VF2M-B1LC20 pressure gauge, 3000 psi bottom, -15 to 30 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GR2M-VJ2M-00LC20 pressure gauge, 3000 psi bottom, -15 to 100 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GR2M-VJ2M-B1LC20 pressure gauge, 3000 psi bottom, -15 to 100 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GT2M-GB2M-00LC20 pressure gauge, 5000 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GT2M-GB2M-B1LC20 pressure gauge, 5000 psi bottom, 5 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GT2M-GC2M-00LC20 pressure gauge, 5000 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GT2M-GC2M-B1LC20 pressure gauge, 5000 psi bottom, +/-15 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GT2M-VF2M-00LC20 pressure gauge, 5000 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GT2M-VF2M-B1LC20 pressure gauge, 5000 psi bottom, -15 to 30 psi top connection, both 1/4" MNPT, Bluetooth radio$1,445.82
LC20-GT2M-VJ2M-00LC20 pressure gauge, 5000 psi bottom, -15 to 100 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GT2M-VJ2M-B1LC20 pressure gauge, 5000 psi bottom, -15 to 100 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GV2M-GB2M-00LC20 pressure gauge, 10000 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GV2M-GB2M-B1LC20 pressure gauge, 10000 psi bottom, 5 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GV2M-GC2M-00LC20 pressure gauge, 10000 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GV2M-GC2M-B1LC20 pressure gauge, 10000 psi bottom, +/-15 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GV2M-VF2M-00LC20 pressure gauge, 10000 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GV2M-VF2M-B1LC20 pressure gauge, 10000 psi bottom, -15 to 30 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GV2M-VJ2M-00LC20 pressure gauge, 10000 psi bottom, -15 to 100 psi top connection, both 1/4" Male NPT$1,263.47
LC20-GV2M-VJ2M-B1LC20 pressure gauge, 10000 psi bottom, -15 to 100 psi top connection, both 1/4" MNPT, Bluetooth radio$1,461.47
LC20-GX2H-GB2M-00LC20 pressure gauge, 15000 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GX2H-GB2M-B1LC20 pressure gauge, 15000 psi bottom, 5 psi top, Bluetooth radio$1,493.84
LC20-GX2H-GC2M-00LC20 pressure gauge, 15000 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GX2H-GC2M-B1LC20 pressure gauge, 15000 psi bottom, +/-15 psi top, Bluetooth radio$1,493.84
LC20-GX2H-VF2M-00LC20 pressure gauge, 15000 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GX2H-VF2M-B1LC20 pressure gauge, 15000 psi bottom, -15 to 30 psi top, Bluetooth radio$1,493.84
LC20-GX2H-VJ2M-00LC20 pressure gauge, 15000 psi bottom, -15 to 100 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GX2H-VJ2M-B1LC20 pressure gauge, 15000 psi bottom, -15 to 100 psi top, Bluetooth radio$1,493.84
LC20-GY2H-GB2M-00LC20 pressure gauge, 20000 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GY2H-GB2M-B1LC20 pressure gauge, 20000 psi bottom, 5 psi top connection, Bluetooth radio$1,493.84
LC20-GY2H-GC2M-00LC20 pressure gauge, 20000 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GY2H-GC2M-B1LC20 pressure gauge, 20000 psi bottom, +/-15 psi top connection, Bluetooth radio$1,493.84
LC20-GY2H-VF2M-00LC20 pressure gauge, 20000 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GY2H-VJ2M-00LC20 pressure gauge, 20000 psi bottom, -15 to 100 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GY2H-VJ2M-B1LC20 pressure gauge, 20000 psi bottom, -15 to 100 psi top connection, Bluetooth radio$1,493.84
LC20-GZ2H-GB2M-00LC20 pressure gauge, 30000 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GZ2H-GB2M-B1LC20 pressure gauge, 30000 psi bottom, 5 psi top connection, Bluetooth radio$1,493.84
LC20-GZ2H-GC2M-00LC20 pressure gauge, 30000 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GZ2H-GC2M-B1LC20 pressure gauge, 30000 psi bottom, +/-15 psi top connection, Bluetooth radio$1,493.84
LC20-GZ2H-VF2M-00LC20 pressure gauge, 30000 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GZ2H-VF2M-B1LC20 pressure gauge, 30000 psi bottom, -15 to 30 psi top connection, Bluetooth radio$1,493.84
LC20-GZ2H-VJ2M-00LC20 pressure gauge, 30000 psi bottom, -15 to 100 psi top connection, both 1/4" Male NPT$1,295.84
LC20-GZ2H-VJ2M-B1LC20 pressure gauge, 30000 psi bottom, -15 to 100 psi top connection, Bluetooth radio$1,493.84
LC20-VJ2M-GB2M-B1LC20 pressure gauge, -15 to 100 psi bottom, 5 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
LC20-VJ2M-VF2M-B1LC20 pressure gauge, -15 to 100 psi bottom, -15 to 30 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
LC20-VL2M-GB2M-00LC20 pressure gauge, -15 to 300 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,018.40
LC20-VL2M-GB2M-B1LC20 pressure gauge, -15 to 300 psi bottom, 5 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
LC20-VL2M-GC2M-00LC20 pressure gauge, -15 to 300 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,018.40
LC20-VL2M-GC2M-B1LC20 pressure gauge, -15 to 300 psi bottom, +/-15 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
LC20-VL2M-VF2M-00LC20 pressure gauge, -15 to 300 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,018.40
LC20-VL2M-VF2M-B1LC20 pressure gauge, -15 to 300 psi bottom, -15 to 30 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
LC20-VN2M-GB2M-00LC20 pressure gauge, -15 to 500 psi bottom, 5 psi top connection, both 1/4" Male NPT$1,018.40
LC20-VN2M-GB2M-B1LC20 pressure gauge, -15 to 500 psi bottom, 5 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
LC20-VN2M-GC2M-00LC20 pressure gauge, -15 to 500 psi bottom, +/-15 psi top connection, both 1/4" Male NPT$1,018.40
LC20-VN2M-GC2M-B1LC20 pressure gauge, -15 to 500 psi bottom, +/-15 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
LC20-VN2M-VF2M-00LC20 pressure gauge, -15 to 500 psi bottom, -15 to 30 psi top connection, both 1/4" Male NPT$1,018.40
LC20-VN2M-VF2M-B1LC20 pressure gauge, -15 to 500 psi bottom, -15 to 30 psi top connection, both 1/4" MNPT, Bluetooth radio$1,216.40
